Blackmagic Design Video Assist 3G-SDI/HDMI 5″ Recorder/Monitor

$525.00

Video Assist 3G-SDI/HDMI 5″ Recorder/Monitor

HYPERD/AVIDA03/5

SKU: HYPERD/AVIDA03/5 Categories: , Tag:

Description

Key Features
  • 1920 x 1080 5″ Touchscreen LCD
  • HDMI & 3G-SDI Video Inputs
  • Records up to 1080p60 Video
  • USB Type-C Webcam Video Output
  • Stores to 1 x SDXC/SDHC Memory Card
  • Loop-Through Video Outputs
  • Waveform, Vectorscope & Histogram
  • Focus Peaking, False Color & Zebra
  • 11 x Display Language Options
  • Dual Sony L-Series Type Battery Slots



Blackmagic Design Video Assist Specs

Display
Panel Type LCD
Display Size 5.0″ / 12.7 cm
Resolution 1920 x 1080
Aspect Ratio 16:9
Viewing Angle Horizontal: 135°
Touchscreen Yes
Maximum Brightness 300 nits / cd/m2
HDR Compatibility None
Pixels Per Inch (ppi) 441 ppi
Color Gamut 100% Rec. 709
Real-Time LUT Monitoring SDR
Image Controls Anamorphic De-Squeeze, Blue Only, False Color, Focus Peaking, Histogram, Image Flip, Picture-in-Picture, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra
Video I/O 1 x HDMI Input
1 x Micro BNC (3G-SDI) Input
1 x HDMI Output
1 x Micro BNC (3G-SDI) Output
1 x USB-C Output
HDCP Support Yes
Embedded Audio HDMI: 8-Channel
SDI: 16-Channel
Audio I/O 1 x 1/8″ / 3.5 mm Headphone Output
Built-In Speaker 1
Power I/O 1 x Barrel Input
Media/Memory Card Slot Single Slot: SD/SDHC/SDXC (UHS-I)
Wi-Fi None
Format Support
Video Format SDI (10-Bit 4:2:2 YUV)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576i: 50
480i: 59.94
HDMI (10-Bit)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576i: 50
480i: 59.94
Timecode Support Yes
Recording
Pulldown Conversion None
Camera Trigger None
Pre-Roll Record None
Encoding Formats Up to 1920 x 1080
ProRes 422, 422 HQ, LT, Proxy 10-Bit 4:2:2 at up to 60 fps
DNxHD 145, 145 MXF, 220x, 220x MXF, 45, 45 MXF 10-Bit 4:2:2 at up to 60 fps
Maximum Audio Tracks 16
Metadata Tagging Yes
Phantom Power None
Power
DC Input Power 12 VDC
Built-In Battery None
Battery Type 2 x L-Series
Mounting
Mounting 6 x 1/4″-20 Female
Environmental
Operating Temperature 32 to 72°F / 0 to 40°C
Operating Humidity 0 to 90%
Storage Temperature -4 to 113°F / -20 to 45°C
General
Material of Construction Aluminum
Dimensions 5.83 x 3.54 x 1.44″ / 14.81 x 8.99 x 3.66 cm
Weight 14.46 oz / 410 g
