Description
Key Features
- 8-Lane PCIe Gen2 I/O Card
- Multi-Rate 12G-SDI & HDMI Connections
- Supports UHD 4K & DCI 4K up to 60 fps
- Single & Dual-Link 4:4:4:4/4:2:2 Signals
- 3D Stereoscopic SDI Output at 4:4:4:4
- Up/Down/Cross Conversion
- Optional Optical Fiber I/O Modules
- Breakout Cable for Analog / RS-422
- Genlock & Deck Control
- Compatible with Mac, Windows & Linux
Blackmagic Design Extreme Specs
Inputs / Outputs
| System Connection | PCIe 2.0Â x8 |
| Video Inputs | 2 x BNC (12G-SDI) 1 x HDMI (HDMI 2.0b) 1 x 3BNC (Component/Composite/S-Video) |
| Audio Inputs | None |
| Video Outputs | 2 x BNC (12G-SDI) 1 x HDMI (HDMI 2.0b) 1 x 3BNC (Component/Composite/S-Video) |
| Simultaneous Multi-Input Support | Yes: 2 Simultaneous Inputs |
Format Support
| Input Video Format | Component / Composite / SDI (8/10/12-Bit 4:4:4/4:2:2) DCI 4K at 23.98/24 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2K 23.98/24/25 fps DCI 2KPsF 23.98/24/25 fps 1080p 25/29.97/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps 576i / 625 lines 50 fps 480i / 525 lines 59.94 fps HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0) DCI 4K at 23.98/24 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps 1080p 23.98/24/25/29.97/30/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps 576i / 625 lines 50 fps 480i / 525 lines 59.94 fps Component 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 1080i 50/59.94/60 fps 576i / 625 lines 50 fps 480i / 525 lines 59.94 fps Composite 576i / 625 lines 480i / 525 lines |
| Input Audio Format | AES/EBU |
| Output Video Format | SDI (8/10/12-Bit 4:4:4/4:2:2) DCI 4K at 23.98/24/25 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2K 23.98/24/25 fps DCI 2KPsF 23.98/24/25 fps 1080p 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps 576i / 625 lines 50 fps 480i / 525 lines 59.94 fps HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0) DCI 4K at 23.98/24/25 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps 1080p 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps 576i / 625 lines 50 fps 480i / 525 lines 59.94 fps Component / Composite 480i / 525 lines at 59.94 fps 576i / 625 lines 50 fps |
| Output Audio Format | AES/EBU |
| Embedded Audio | SDI: 16-Channel HDMI: 8-Channel |
Standards
| Video Standard Compliance | SMPTE 259M/292M/296M/372M/425M/435/2108-1/ST-2081/ST-2082/ST-2082-10 ITU -R BT.601/BT.656 |
| HDR Compatibility | Hybrid Log Gamma |
Hardware
| OS Compatibility | macOS 10.15 macOS 11.1 or Later Linux Windows 8.1 Windows 10 *As of April, 2021: Check with manufacturer for the most up-to-date compatibility |
| Power Consumption | Device: 30 W |
Environmental
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| Operating Humidity | 0 to 90% |
General
| Dimensions | 6.69″ / 169.93Â mm |
| Weight | 0.66Â lb / 299Â g |
